Description
The numbers in the text refer to the diagrams on
page 2-6.
1. Handle
2. On/Off switch
3. Release button for dust cup
4. Battery
5. Battery unlock button
6. Motor housing
7. Dust cup
8. Extension tube
9. Suction hose
10. Crevice nozzle
11. Floor nozzle
12. Brush nozzle
13. Holder for nozzles
14. Storage holder
15. Belt hook
16. HEPA filter
17. Suction opening
19. LED indicator button
20. Charger
3. ASSEMBLY
Before any work on the power tool,
remove the battery.
The battery must be charged before first
use.
Inserting the battery into the machine (Fig. C)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Insert the battery (4) into the base of the
machine as shown in Fig. C1.
2. Push the battery further forward until it clicks
into place.
Removing the battery from the machine (Fig. C)
1. Push the battery unlock button (5).
2. Pull the battery out of the machine like shown
in Fig. C1.
Charging the battery (with the charger) (Fig. G)
• Plug the charger plug into an electrical outlet
and wait for a while.
• Plug the output of the charger into the round
socket of the battery. The LED indicator on
the battery (18) will lighten up and show the
charging status.
LED indicator (18)
Fig. G
The battery has 1 LED indicator (18) which
indicates the status of the charging process:
LED
Charger status
Red
Battery charging in progress
Green
Battery charging finished, battery fully charged
• After the battery is fully charged remove the
charger plug from the outlet and remove the
battery from the charger.
When the machine is not being used
over a longer period of time it is best to
store the battery in charged condition.
Assembly of the nozzles (Fig. B)
Either assembly the nozzles (10, 11, 12) directly
to the suction opening (17) of the machine or use
the extension tube (8). Nozzles can also be used
with the suction hose (9) and give more freedom
of movement.
Floor nozzle (11)
The floor nozzle is designed for domestic dry
vacuuming in, for example, the house, workroom
or car.
Crevice nozzle (10)
The crevice nozzle is designed for domestic
dry vacuuming, edges and other areas that are
difficult to access.
Brush nozzle (12)
The brush nozzle is designed for domestic dry
vacuuming, for example cushions of sofa's or
textile furniture.
Nozzle holder (13)
The nozzle holder is designed to hold the included
nozzles. It can be attached to the storage holder
(14) or it can be attached to the extension tube (8)
11
