2. Unpacking operation
Fix the screen bracket on the right side of the machine with two M3*12
5
screws (as shown in Figure a);
Connect both ends of the telephone line to the right side of the
machine and the screen po爀琀 respectively (as shown in Figures b and c);
Place the display screen on the screen bracket. Connect the WIFI
antenna (as shown in Figures d and e).
M3*12
c
Inse爀琀 the 3pin line of broken material detection into the broken materi-
6
al detection po爀琀; Then inse爀琀 the 2pin line of the top LED lamp into the
LED lamp po爀琀; Finally, inse爀琀 the 4pin wire of the motor into the motor
po爀琀s on both sides of the Z axis.
Material break
detection
LED light
Z-axis machine
05
b
a
Display cable
d
e
WIFI Antenna
Z-axis machine
Inse爀琀 the 昀氀at cable from the
7
昀椀xed sheet metal pa爀琀 and then
inse爀琀 it into the horn head po爀琀
at the top of the extrusion head.
Inse爀琀 the 6pin wire of the motor
9
into the X-axis motor po爀琀.
M5 gasket
Use one M3*4 screw to 昀椀x the R-type clamp
8
at the rear end of the X-axis 昀椀xture.
M3*4
Use two M5*10 screws to 昀椀x the upper end
10
of the inclined tie rod, and then use two
M5*16 screws to 昀椀x the lower end of the
inclined tie rod. (4 M5 gaskets should be
added during installation to prevent
loosening.)
M5*10
M5 gasket
M5*16
M5*10
M5*16
