Version with retracts and "Pico Std" servo
the servo that the axle runs parallel to the servo
(roughen up glue areas first).
Attach the (small) nose wheel and secure it with
a small silicone
ring. Now glue the servo with UHU Por to the
servo plate. Make sure that the wheel is
centered to the servo plate and that the landing
gear leg rests against the plate when lowered.
Now install the connecting rod, drive wire and
bell crank as shown.
Attention: Do not glue bell crank and landing
gear axle together yet.
Connect the connecting rod to the rear bell
crank and now glue the complete
unit into the fuselage, making sure that all bell
cranks are perpendicular.
the fuselage by using sand paper.
Within the wheel axle area you probably have
to take off some more
Put one of the
axle brackets on
the axle and insert
the axle
into the mounting
bracket at the
servo as shown.
Glue the
axle bracket under
Widen the outer
hole of the servo
lever to a
diameter of
th
1.5mm (1/16 in.)
and put the lever
perpendicular to
the servo as
shown.
Next cut out the
wheel housings
along the
markings and
match them to
one another and
to the shape of
Make sure that the wheels have sufficient room
to retract. Now put on the
upper panels. Just like on the
original the wheels will protrude somewhat
from the wheel housings when retracted.
Rotate the landing gear legs in such a way, that
the servo is in center position and the legs are
standing forward at approx. 45°. Plug the servo
into the receiver and check the function.Adjust
the bell cranks, that the legs are as vertical as
possible when lowered, and that the servos are
not running up against anything in any position.
hole of the front bell crank to a diameter of
th
1.5mm (1/16 in.). Now connect in the
connecting rod and secure
it as shown with a small screw. You may use
e.g. one of the
back-up screws of the Piccolo servos. Glue the
crank on the axle (do not glue it on yet).
Connect the connecting rod at the rear bell
crank and glue the whole unit into the fuselage
with the wheel centered to the fuselage and the
landing gear leg resting against the fuselage
front bottom. Readjust the bell cranks that the
legs are extending vertically downward, and
secure them with some CA glue. Now install the
wheel housings as described before.
material (cut out,
or carefully melt
out with a
soldering iron).
Now first glue on
the lower panels
with UHU Por.
Next install the
wheels.
If everything fits
well, secure the
bell cranks with
some CA glue.
With fixed
landing gear
without servo
Widen the center
four die-stamped
polystyrene plates
to the servo plate
as shown, and
push the landing
gear axle through.
Attach the (small)
nose wheel and
secure it with
a small silicone
ring. Put the bell
