5.2 DATA AVAILABLE
5.2.1 General parameters
Register Address
1001 1000
1002 1001
1003 1002
1004 1003
1005 1004
1006 1005
1007 1006
1008 1007
1009 1008
1010 1009
1011 1010
1012 1011
1013 1012
1014 1013
1015 1014
1016 1015
1017 1016
1018 1017
1019 1018
1020 1019
1021 1020
1022 1021
1023 1022
1025~1027 1024~1026
1028 1027
1029 1028
1030 1029
1031 1030
1032~1050 1031~1049
1051 1050
1052 1051
10 PMML0359A rev.1 - 06/2015
Description
Control Unit Run/Stop
Control Unit Mode
Control Circuit 1 Run/Stop
Control Heat. OTC Circuit 1
Control Cool. OTC Circuit 1 (2)
Control Circuit 1: Thermostat Setting
Control Circuit 1: Room Ambient Temperature
Control Circuit 1: Water Heating Setting Temp
Control Circuit 1: Water Cooling Setting Temp (2)
Control Circuit 2 Run/Stop
Control Heat. OTC Circuit 2
Control Cool. OTC Circuit 2 (2)
Control Circuit 2: Thermostat Setting
Control Circuit 2: Room Ambient Temperature
Control Circuit 2: Water Heating Setting Temp
Control Circuit 2: Water Cooling Setting Temp (2)
Control DHWT Run/Stop
Control DHWT Setting Temperature
Control Swimming Pool Run/Stop
Control Swimming Pool Setting Temperature
Control AntiLegionella Run/Stop
Control AntiLegionella Setting Temperature
Control Block menu
(Reserved)
Space mode
DHW Mode
Room Thermostat available
Control Eco offset
(Reserved)
Status Unit Mode
Status Circuit 1 Run/Stop
Value
0: Stop
1: Run
0: Cool (2)
1: Heat
0: Stop
1: Run
0: No
1: Points
2: Gradient
3: Fix
0: No
1: Points
2: Fix
50~350 (5,0~35,0)
0~1000 (0,0~100,0)
0~80 (3)
0~80 (3)
0: Stop
1: Run
0: No
1: Points
2: Gradient
3: Fix
0: No
1: Points
2: Fix
50~350 (5,0~35,0)
0~1000 (0,0~100,0)
0~80 (3)
0~80 (3)
0: Stop
1: Run
0~80 (3)
0: Stop
1: Run
0~80 (3)
0: Stop
1: Run
0~80 (3)
0: No
1: Block
0: Comfort
1: ECO
0: Standard
1: High demand
0: No available
1: Available
1~10
0: Cool (2)
1: Heat
0: Stop
1: Run
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R
R
