Main Unit (Nvr) Front Panel; Main Unit (Nvr) Rear Panel - ieGeek IE92 Bedienungsanleitung

04
①
Power lamp Lights
②
Recording lamp
③
Warning lamp
05
① ②
①
power switch
②
PoE LAN
Audio output
③
terminal
Video output
④
terminal (VGA)
Video output
⑤
terminal (HDMI)
/ Main unit (NVR) Front
Panel
red when the power is on.
Lights up when recording.
If settings such as motion
detection are made, this lights
up when motion is detected.
/ Main unit (NVR) Rear
Panel
Turn the power 0N/OFF.
Connect the point camera with
a LAN cable.
Connect the audio terminal
of the beaker (please prepare
separately).
* Connect to the monitor using
an HDMI cable.
Not required if you have
Connect to the monitor using
a VGA cable (please prepare
separately).
* Connect to the monitor using
an HDMI cable.
Not required if you have
Connect to the monitor using
an HDMI cable (please prepare
separately).
