Restistance to shock
Protection class
Permissible installation altitude above sea level, maximum
Umgebungsbedingungen - Isolationskennwerte
Rated insulation voltage U
i
Rated impulse withstand voltage U
Overvoltage category
Degree of pollution
Elektrische Daten
Operating voltage
No-load supply current I
, typical
0
Current consumption with magnet ON, average
Current consumption with magnet ON, peak
Rated operating voltage
Operating current
Required rated short-circuit current
External wire and device fuse rating
Time to readiness, maximum
Switching frequency, maximum
Electrical fuse rating, maximum
Elektrische Daten - Magnetansteuerung
Designation, Magnet control
Switching thresholds
Magnet switch-on time
Test pulse duration, maximum
Test pulse interval, minimum
Classification ZVEI CB24I, Sink
Classification ZVEI CB24I, Source
Elektrische Daten - Sichere digitale Eingänge
imp
30 g / 11 ms
III
2.000 m
32 VDC
0,8 kV
III
3
24 VDC -15 % / +10 % (stabilisiertes PELV-Netzteil)
50 mA
200 mA
700 mA / 100 ms
24 VDC
1.200 mA
100 A
2A gG
4.000 ms
1 Hz
2 A
IN
-3 V ... 5 V (Low)
15 V ... 30 V (High)
100 %
5 ms
40 ms
C0
C1
C2
C3
