of the guide roller. Remove the nozzle (8)
and unscrew the contact tip (9) from the
head of the welding torch.
For pulling the wire along the sleeve, a
button (4) above the pulling mechanism is
provided. Pulling must be finished when
the wire exits the burner hole by 50-100
mm. Put the contact tip and nozzle back
on the burner.
Connection of a hose for the supply
of protective gas
When connecting, the cylinder and re-
ducer must be closed. The gas supply
system, consisting of a gas cylinder, a
reducer and a gas hose must have tight
connections (use screw clamps).
During MIG/MAG welding, shielding gas
must be used to prevent oxidation of the
metal during the welding process. Unal-
loyed and alloyed steels are preferably
welded in an environment of active pro-
tective gas, for example, carbon dioxide
— MAG (metal active gas welding). High-
ly alloyed materials and such materials as
aluminum, magnesium, nickel-based al-
Metal
Clearance,
thickness,
mm
0,8
1
1,2
1,6
2
Performing welding works in semi-automatic mode (MIG/MAG) (Fig. 10)
Switching between welding modes in semi-automatic mode and electrode welding
(MIG/MMA) is performed by the switch (1).
Metal
thickness,
mm
0,8
1
1,2
1,6
2
10
Wire
mm diameter, mm
0 0,6
0 0,6
0 0,8
0 0,8
0-0,5 0,8
Wire
Clearance,
diameter,
mm
mm
0 0,6
0 0,6
0 0,8
0 0,8
0-0,5 0,8
loys, titanium are welded in an environ-
ment of inert shielding gas, for example,
argon — MIG (metal inert gas welding).
Performing welding works in semi-
automatic mode (MIG/MAG) (Fig. 9)
Switching welding modes is performed
by the switch (1) (Fig. 9):
MMA - manual arc welding mode;
08/СО - semi-automatic welding mode
2
with the addition of carbon dioxide;
08/Ar-СО - semi-automatic welding
2
mode with the addition of a mixture of
carbon dioxide and argon;
Flux cored - welding mode with flux-coat-
ed wire without gas;
TIG LIFT - argon arc welding with the help
of a special sleeve for igniting a tungsten
electrode by touch.
WA RN IN G !
The ambient temperature during
welding should be in the range from
-5 °C to +55 °C.
Operating Wire speed,
voltage, V m/min
13-15 2,5-3,5
15-17 2,5-3,5
17-18 2,5-4,5
18-19 3,5-5,5
19-20 5,5-7,5
Operating Wire speed,
voltage, V m/min
13-15 2,5-3,5
15-17 2,5-3,5
17-18 2,5-4,5
18-19 3,5-5,5
19-20 5,5-7,5
Gas
consumption,
l/min
8-9
8-10
10-12
10-15
10-15
Gas
consumption,
l/min
8-9
8-10
10-12
10-15
10-15
