Degree of protection
Ambient temperature
Storage and transport temperature
Relative humidity, maximum
Note (Relative humidity)
Resistance to vibrations
Restistance to shock
Protection class
Permissible installation altitude above sea level, maximum
Umgebungsbedingungen - Isolationskennwerte
Rated insulation voltage U
i
Rated impulse withstand voltage U
Overvoltage category
Degree of pollution
Elektrische Daten
Operating voltage
No-load supply current I
, typical
0
Current consumption with magnet ON, average
Current consumption with magnet ON, peak
Rated operating voltage
Operating current
Required rated short-circuit current
External wire and device fuse rating
Time to readiness, maximum
Switching frequency, maximum
Elektrische Daten - Magnetansteuerung
Designation, Magnet control
Switching thresholds
Current consumption at 24 V
imp
IP67
IP66
-25 ... +60 °C
-25 ... +85 °C
93 %
nicht kondensierend
nicht vereisend
10 ... 150 Hz, Amplitude 0,35 mm
30 g / 11 ms
III
2.000 m
32 VDC
0,8 kV
III
3
24 VDC -15 % / +10 % (stabilisiertes PELV-Netzteil)
50 mA
200 mA
700 mA / 100 ms
24 VDC
1.200 mA
100 A
2 A gG
4.000 ms
1 Hz
IN
-3 V ... 5 V (Low)
15 V ... 30 V (High)
10 mA
8-29
