ANALOGUE OUTPUTS

2x
RCA stereo unbalanced
1x
XLR stereo balanced
1x
Tube Output (for the TUBE-1012 and
TUBE-1006 external stages)
|
Output level:
2 Vrms standard up to 2,5 Vrms max

ANALOGUE INPUTS

2x
RCA PHONO stereo unbalanced (0.1mV
MC up to 8.0mV MM)
1x
XLR PHONO stero balanced for MC only
(0.1mV up to 1.0mV MC)
PH-1000 MODELS
PH-1000 is available in three models, each with different specifications.
MODELS
Class A preamp
Headphone output
Line input
External load
Gain MM 40dB – MC 60dB
EQ curves
EQ manual
adjustments
RS-232
L/R swap
PH-1000 LITE
–
Stereo jack 6.3mm
–
–
36
–
–
–
4
EXTERNAL LOAD AND LINE INPUTS
(PH-1000/PH-1000 LINE)
1x
RCA stereo unbalanced:
Select RCA 3 to connect other audio
sources or an external load for fine
adjustment (applied for RCA 2 only)
1x
XLR stereo balanced:
Select XLR 2 to connect other audio
sources
|
Line input level:
2 Vrms standard up to 2,5 Vrms max
UPGRADES
|
PSU-1250 & PSU-1000 external power
supplies
|
TUBE-1012 & TUBE-1006 valve output
stages
PH-1000
–
Stereo jack 6.3mm
–
Yes
MM 40dB – MC 65dB
Completely adjustable
4 memory slots
Yes
Yes
PH-1000 LINE
Yes
Stereo jack 6.3mm
2
Yes
MM 40dB – MC 65dB
Completely adjustable
4 memory slots
Yes
Yes
