EX-1147HMVS
3. Layout, Connections & Jumper Settings
3.2 Connections
USB 3.2 Gen 1 C-Port:

3.3 Jumper Settings

The two internal jumpers Bus Power (JP2) and Host Control (JP3) can be used to configure the
power output on the downstream ports as required.
JP2
JP3
The possible settings and their effects are shown in the following table.
© Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved
DIS
ENA
ON HOST
Note!
By dual assignment of the pins, the USB
Type-C plug can be plugged into the port
on both sides.
11
English
