LR DDP-2 Bedienungsanleitung Seite 26

MANUAL
Measuring assemblies
Proven measuring assemblies for various types of media. The assemblies that are
par cularly recommended for use are shown below.
Filling of
the measu -
liquid
ring line
Examples
condensate
Pressure
gauge
above the
tapping
point
Pressure
gauge
below the
tapping
point
Dimensions in mm
Tel. +49 (0) 7121-90920-0 • Fax +49 (0) 7121-90920-99 • DT-Info@Leitenberger.de • www.druck-temperatur.de • www.LR-Cal.net
Differenzdruckmessgerät DDP-2
Differen al pressure gauge DDP-2
liquid media
liquid with
vapour
boiling liquid
DRUCK & TEMPERATUR Leitenberger GmbH • Bahnhofstr. 33 • D-72138 Kirchentellinsfurt • GERMANY
vapour gaseous
only
"lique ied f
dry air
gases"
26
gaseous media
par ally completely
condensed condensed
(damp)
moist air
steam
flue gases
