Installation Overview

Your appliance facilitates three different installation configurations: three-sided, two-sided, and
single-sided.
Two-sided installation
Glass exposed on front AND left OR right sides.
Appliance is fully recessed into the wall with
one side open.
Three-sided installation
Glass exposed on front, left, AND right sides.
Appliance is fully recessed into the wall with
both sides open.
Single-sided installation
Glass exposed on front ONLY.
Appliance is fully recessed into the wall.
www.aflamo.com
5
