Parts and Hardware
A – Fireplace
E - Log-sets
Specification and Dimension
B
Model Number
AV-WM100UNI-NH
AV-WM120UNI-NH
AV-WM140UNI-NH
AV-WM160UNI-NH
AV-WM180UNI-NH
F-Decorative
Crystals - Large
A
A
1000mm
1200mm
1400mm
1600mm
1800mm
www.aflamo.com
B-Wood Screws
G-Decorative
Crystals
(Clear&Smoky)
B C
460mm 232mm
460mm 232mm
460mm 232mm
460mm 232mm
460mm 232mm
C- Drywall anchors
D-Remote Control
H-Wall Bracket
Fixed on back of firebox
D
D
380mm
380mm
380mm
380mm
380mm
I- "L" bracket
C
E
E
140mm
140mm
140mm
140mm
140mm
