2.5 |SpOILERMONTAGE

Round head selftaping screw 3x12
Round head machined screw M3x15
Round head selftaping screw 4x22
4150-0001_manual_virus3_kit_12-08.indd 9
All manuals and user guides at all-guides.com
4150-0032
6x
4150-0032
(3x12)
(3x12)
2x
2x

2.5 | WING ASSEMBLy

(3x12)
(3x12)
(M3x15)
(M3x15)
(4x22)
(4x22)
