QT-12HS/HR/HB/HY/BL
QT-12ES/ER/EB/EY
PLEASE
REFER
TO THE
OPERATION
MANUAL.
FOR
A COMPLETE
DESCRIPTION
OF THE
OPERATION
OF THIS
UNIT,
SPECIFICATIONS
GENERAL
Power source:
AC 110V ~ 120V and 220V ~ 240V,
Tape:
50/60Hz
Frequency response:
DC 9V (UM/SUM-2, R14, HP-11 or
Signal/noise ratio:
C type x 6)
Wow and flutter:
Speakers:
9 cm (3-1/2"") x 2
Output power:
QT-12HS/HR/HB/
HY/BL;
(DIN 45 324)
MPO; 3.4W + 3.4W (AC operation)
RMS; 2.3W + 2.3W (DC operation,
10% distortion)
QT-12ES/ER/EB/
RADIO
EY:
MPO; 3.6W + 3.6W (AC operation)
RMS; 2.3W + 2.3W (DC operation,
10% distortion)
Input impedance:
Output impedance:
Frequency range:
TAPE RECORDER
Compact cassette tape
50Hz ~ 10,000Hz
45 dB
QT-12HS/HR/HB/HY/BL; 0.3%
(DIN 45 511)
QT-12ES/ER/EB/EY; 0.3% (CCIR)
External mic; 600 ohms
DIN socket; 0.56mV/2.5K ohms
Headphones; 8 ~ 32 ohms
LW;
150 kHz ~ 285 kHz
MW;
520 kHz ~ 1,620 kHz
SW;
5.95 MHz ~ 18.0 MHz
FM;
87.6 MHz
~ 108 MHz
Specifications for this model are subject to change a
Semiconductors:
5 ICs
6 transistors
12 diodes
2 LEDs
Dimensions:
Width;
404 mm (16")
Height;
136.5 mm (5-3/8')
'
;
Depth; 79.5 mm (3-1/8")
RUSE NONCE:
Weight:
2.0 kg (4.5 Ibs.) without batteries
NAMES
OF
PARTS
1. FM/SW Telescopic Rod Antenna
11. Record Button
2. Volume Control
12. Tone Control
3. Balance Control
13. Band Selector
4. Mode Selector
14. Tuning Control
5. Function Selector
15. Built-in Microphone (L-ch)
6. Pause Button
16. Power Indicator
7. Stop/Eject Button
17. FM Stereo Indicator
8. Fast-forward Button
18. Built-in Microphone (R-ch)
9. Rewind Button
19. Speaker (L-ch)
10. Playback Button
20. Digital Tape Counter
21. Tape Counter Reset Button
22. Cassette Holder
23. Speaker (R-ch)
24. DIN Socket
25. External Microphone Jacks
26. Battery Compartment Lid
27. Beat Cancel Switch
28. Headphones Jack
29. AC Power Supply Socket
2
3
45
67891011
12
13
«14
Figure 2—1
15
1617
18
SucaS)
Ean
—
3S
2425
26
27
Figure 2—3
Figure
2—4
