Safety And Mounting Information - Inventronics Ls/Pd Lt2 Li Uf Montagehinweise

 LS/PD LT2 LI UF
Sensor for OTi DALI
Ultraflat LED drivers
1)
Connection (Master/Slave) 2)
Operating voltage 3)
Power consumption 4)
Sensor connection 5)
External Push button connection total wire length 6)
External push button 7)
Light sensing range 8)
t a
t c 9)
Type of protection 10)
Wire preparation /
Anschluss Vorbereitung
Wiring scheme
with two LED drivers /
Anschluss-Schema
16)
mit zwei LED Treibern
Presence detection range (= usage at workplaces) /
Präsenzerfassungsbereich (= Einsatz an Arbeitsplätzen)

SAFETY AND MOUNTING INFORMATION:

The LS/PD LT2 LI UF sensor is exclusively designed for luminaire integration. Unit is permanently damaged if mains is applied to the sensor interface. As
the LEDset interface of the LED driver is not galvanically separated from the mains connection of the driver, the sensor interface must not be touchable
and the unit has to be put out of operation when the housing or the PIR lens is damaged. 1) Light and presence sensor exclusively designed for OTi DALI
Ultraflat LED drivers; 2) Connection interface; 3) Operating voltage; 4) Power consumption; 5) Allowed wire connection length to the LED drivers per
output; 6) Allowed total wire length to all external push buttons; 7) Suitable push button: 230VAC type with push to make contact; 8) Light sensor range
of operation (measured at the sensor); 9) Max. allowed casing temperature at the test point; 1 0) Type of protection; 1 1) Dimension drawing; 1 2) Optional
restriction of detection range to ~50% by click-on shutters; 1 3) Recommended wire preparation, wire with basic insulation required; 1 4) Wiring scheme
with one LED driver; 1 5) External push button; 1 6) Wiring scheme with two LED drivers; 1 7) Presence detection range at working place applications;
1 8) Presence detection range at 2m mounting height; 1 9) Presence detection range at 3m mounting height; 2 0) Motion detection range at corridor use
case applications; 2 1) Motion detection range at 2m mounting height; 2 2) Motion detection range at 3m mounting height; 2 3) Motion detection range at
4m mounting height
Inventronics GmbH
Berliner Allee 65
86153 Augsburg
Germany
www.inventronicsglobal.com
LEDset / LED-aux
5V DC
30mW
≤ 1m
≤ 25m
230 V AC
10...1000 lx
0...+50 °C
55 °C
IP20
Wiring scheme with one LED driver /
13)
Anschluss-Schema mit einem LED Treiber
2 m mounting height
(=max) mounting height
Dimensions /
11)
Abmessungen
9)
15)
15)
Motion detection range (= usage in corridors) /
17)
Bewegungserfassungsbereich (= Einsatz in Korridoren)
1 8)
3 m
19)
2
Restrict detection range /
Erfassungsbereich einschränken
14)
2 m mounting height
mounting height
mounting height
12)
20)
2 1
) 3 m
2 2)
4 m (=max)
23)
