RTF-Trend
Maximum product lifetime is achieved if the product is not turned
off but set at the lowest possible set point / frost protection when
heat is not required.
Notice
The language used in the original documentation is
English.
Other language versions are translations of the original
documentation.
The manufacturer cannot be held liable for any errors in the
documentation. The manufacturer reserves the right to make
alterations without prior notice.

INSTALLING THE SENSOR

• Insert the sensor cable into a non-conductive conduit
embedded in the floor.
• The end of the conduit must be sealed and the conduit placed
as high as possible in the concrete layer.
• The floor sensor must be centred between loops of heating
cable.
• The two wires from the sensor to the thermostat must be kept
separate from high-voltage wires/cables. Place the sensor cable
in a separate conduit or segregate it from power cables in some
other way. Ensure that the insulation is undamaged on both the
electrical wiring and the floor sensor. Never use two spare wires
in a multi-core cable.
PLACEMENT OF THE THERMOSTAT
The thermostat should be mounted on the wall approx. 1.5 m
above the floor in such a way as to allow free air circulation
around it. Draughts and direct sunlight or other heat sources
must be avoided.
OPENING THE THERMOSTAT
1. Switch off the thermostat
2. Insert a small screwdriver in the bottom right slot of the
thermostat.
3. Turn the handle of the screwdriver outwards while gently pulling
the right side of the bottom a few millimetres towards you.
4. Insert the small screwdriver into the bottom left of the
thermostat.
(FIG. 2)
(FIG. 4)
