Display mode settings

Set one of the four display patterns that shows whether your instrument is out of
tune. The factory setting is Regular mode.
1. Press the DISPLAY/BRIGHT button.
The current setting will blink for several seconds in the note name display.
2. When the setting is shown in the note name display, press the DISPLAY/
BRIGHT button again to set the display mode.
Each time you press the DISPLAY/BRIGHT button you will cycle through the
following settings.
With all display modes, the tuning guide LEDs indicate whether the pitch is
high or low. When the tuning is correct, both  and  light up. If the pitch
is flat, the  lights up; and if the pitch is sharp, the  lights up.
1: Regular
Tune your instrument until the LED at the center of the LED meter lights up
brightly.
The right-hand LEDs in the LED meter light up if the pitch is high, and the
left-hand LEDs light up if the pitch is low.
The pitch
is at.
2: Strobe
Tune your instrument until the LEDs stop running. Since the strobe meter has
a higher precision, it allows you to tune with greater accuracy.
The LEDs light up, running from left to right if the pitch is high and from right
to left if the pitch is low.
The pitch
is at.
3: Half-strobe
Tune your instrument until the LEDs stop running and only the center LED is lit.
The right-hand LEDs will strobe if the pitch is high, and the left-hand LEDs will
strobe if the pitch is low.
The pitch
is at.
In tune.
In tune.
In tune.
6
The pitch
is sharp.
The pitch
is sharp.
The pitch
is sharp.
