Zipper Maschinen ZI-COM50-2V5E Betriebsanleitung Seite 30

1 Screw
2 gasket
3 Cylinder head cover
4 screw
5 gasket
6 Cylinder head
7 Gasket for cylinder head
8 Air filter
9 Valve piece
10 Al. gasket
11 Valve plate
12 valve plate gasket
13 cylinder
14 bolt
15 washer
16 piston
17 Piston pin
18 cirlip
19 connection rod
20 connection rod
21 key
22 crank shaft
23 Flat gasket
24 screw
25 Rubber plate
26 oil bresther
27 O ring
28 Front cover
29 gasket
30 Oil gauge
31 bolt
32 screw
33 gasket
34 washer
35 bolt
36 bolt
37 Washer
75 Pressure switch
76 connector
77 gauge
78 Releas pipe
79 Single valve
80 cable
81 Pressure pipe
82 Rubber hand
83 tank
84 screw
85 washer
ZIPPER MASCHINEN GmbH
ZI-COM50-2V5E
3
3
1
1
1
1
5
1
1
1
1
1
1
1
1
1
1
1
2
4
2
2
4
4
2
2
2
2
4
2
2
2
8
8
2
4
4
2
2
2
1
1
1
1
1
1
1
1
www.Zipper-Maschinen.at
ERSATZTEILE / SPARE PARTS
38 screw
39 Washer
40 Flat gasket
41 Bolt
42 Bearing
43 Oil seal
44 Piston ring
45 Air cooler
46 Ellow
47 Cooper pipe cover
48 Bolt
49 Cooper connector
50 bolt
51 Wire-holder
52 bolt
53 gasket
54 bolt
55 protector
56 motor
57 key
58 wire
59 capacitor
60 rotor
61 bearing
62 Wave gasket
63 Back cover
64 washer
65 bolt
66 fan
67 gasket
68 hold-up of plastic cover
69 cover
70 Quick coupler
71 Regulator valve
72 Pressure switch
73 Double connector
74 Safty valve
86 Air drian
87 Falt gasket
88 Rubber foot
89 Flat gasket
90 screw
91 axle
92 wheel
93 washer
94 screw
95 nut
4
1
1
1
1
1
1
1
3
3
1
1
1
1
1
1
1
1
1
4
1
4
1
4
1
1
1
2
2
2
1
1
4
8
4
2
2
1
1
1
1
1
1
1
1
1
1
30
