AUTO-HAK V36A Montageanleitung Seite 5

Towbar accessories:
Towing hitch (without electrical set)
V36A
Cat. no.
Class: A50-X
Designed for:
Manufacturer: NISSAN
Model: SUNNY Traveller
Type: ESTATE (Y10), except 4x4
produced since 04.1991 till 12.2000
Approval number according to Directive 94/20/EC: e20*94/20*0639*00
This towbar is designed according to rules of safety traffic regulations. The towing
hitch is a safety component and can be install only by qualified personnel. Any
alteration or conversion of the towing hitch is prohibited and would lead to
cancellation of design certification. Remove insulating compound and underseal
from vehicle (if present) in the area of the matting surfaces of the towing hitch.
The vehicle manufacturer's specifications regarding trailer load and max. vertical
cup load are decisive for driving whereat values for the towing hitch cannot be
exceeded.
D-value formula:
Max trailer weight [kg] x Max vehicle weight [kg]
+ Max vehicle weight [kg]
Max trailer weight [kg]
PPUH AUTO-HAK Sp.J.
Produkcja Zaczepów Kulowych
Henryk i Zbigniew Nejman
76-200 SŁUPSK ul. Słoneczna 16K
tel/fax (059) 8-414-414; 8-414-413
e-mail: office@autohak.com.pl
www. autohak.com.pl
Technical data:
D-value: 8,0 kN
maximum trailer weight: 1600 kg
maximum vertical cup mass: 75 kg
Foreword
9,81
D [kN]
X =
1000
