DESCRIPTION
Combined drill driver and auto-feed screwdriver
that can be separated for flexible and varied use.
ASSEMBLY
WARNING!
Switch off the drill driver and remove
the battery before checking, cleaning,
maintenance or adjustments, and before
changing accessories.
FITTING / REMOVING THE BATTERY
1. Remove the battery by pressing the button
on the front of the battery and by pulling
the battery from the drill driver.
2. To fit the battery, align the horns on the
battery to the slots in the casing and press
the battery in place.
3. Press in the battery all the way until it
clicks into place. It is not correctly in place
if the red marking on top of the button
can be seen.
FIG. 1
IMPORTANT:
• Press in the battery all the way.
Otherwise the battery can come loose
and cause personal injury.
• Never attempt to force the battery in
place. If it is not easy to press it in place,
it is not properly aligned.
FITTING / REMOVING BITS
1. Pull off the depth stop.
FIG. 2
2. Grip the bit with pliers and pull it out from
the magnetic bit holder. In some cases the
bit may need to be moved around a little
in order to release it from the bit holder.
3. To fit a bit, slide it into the magnetic bit
holder and press it in place.
4. Fit the depth stop with a strong backward
pressure
FITTING / REMOVING HOOK
The hook is used to hang up the drill driver. It
can be fitted on either side.
1. Fit the hook by inserting it into the slot
on the required side of the drill driver
housing and locking it in place with the
screw.
2. Remove by removing the screw.
FIG. 3
INSTALLATION OF AUTO-FEED
SCREWDRIVER
1. Remove the depth stop and bit holder
from the drill driver.
2. Fit the extended bit that is intended for
the drill driver.
FIG. 4
3. Fit the accessory on the drill driver and
check that it locks in place with a click.
FIG. 5
4. Adjust the depth stop plate according to
the value on the label for the screw length
to be used.
25
30
35
40
45
50
55
FIG. 6
5. Press down the movable part completely
and turn the wheel so that the tip of
the bit sticks out about 5 mm outside
the depth stop plate. Turn the wheel in
direction (A) to push out the bit and in
direction (B) to pull it in.
FIG. 7
EN
25 mm
26–30 mm
31–35 mm
36–40 mm
41–45 mm
46–50 mm
51–55 mm
