Referring to Fig.1:
1 ON/OFF BUTTON
2 SPECIAL PROGRAMME SELECTION BUTTON
3 PROGRAMME SELECTION BUTTON
4 START BUTTON
5 STANDBY LED
Colour codes and operating status
Referring to Fig.2:
Page 6 of 14
INSTRUCTION MANUAL FOR DISHWASHERS
Green (Fig.2a)
- Machine ready
Blue (Fig.2b)
- Washing cycle in progress.
Yellow ( Fig. 2c )
- Machine in preparation stage
- No washing additives
- No salt (versions with integral water softener only)
Red (Fig. 2d )
Serious fault.
- Operation limited or not possible: check error code
signalled and contact technical assistance service if
necessary.

Chap 4 USING THE MACHINE

4.1 Graphic Interface

6 MACHINE STATUS INDICATORS AREA
7 CYCLE INDICATORS AREA
8 TEXT DISPLAY
9 TIME BAR
