Ariete 2712/21 Evolution 2.0 Bedienungsanleitung Seite 30

E N
J
K
W
5
4
X Dirt container
Y Socket for power cord
W Hepa filter support
K HEPA filter (n. 1 extra one)
J Main filter
X
Y
1 Infrared signal transmitters
2 on/off switch
1
3 Lower lid
4 Signal output
2
5 Signal output light
3
