Electromagnetic disturbances should be reduced as much as possible if they disturb the operator's activity. The operator
is responsible for the installation and the use of the welding equipment and should seek advice from the manufacturer
if required.
ELECTRIC WIRING RULE TO REDUCE DISTURBANCES
It is sometimes useful to set all the parts at the same voltage (while respecting the standards in place for each).
Installing an earth connection to the workpiece may reduce the disturbances, and will not increase the risk to the ope-
rator or any other electrical appliances.
The shielding of the welding cables and of any other cables may be useful.
IP PROTECTION
IP23
- Protection prevents access to hazardous parts with fingers or other solid foreign bodies with a diameter equal to or
higher than 12.5mm
- Protective grid - against rain fall at an angle of 60°.
SET UP
Only qualified personnel authorized by the manufacturer should perform the installation of the welding equipment.
During set up, the operator must ensure that the machine is unplugged. The serial or parallel connections on a gene-
rator are prohibited.

TRANSPORTATION OF THE MACHINE

Handle is fitted on the equipment to carry it easily, be careful to not underestimate its weight.
Do not use the cables or torch to move the machine. The welding equipment must be moved in an upright position.
Never lift the machine while there is a gas cylinder on the support shelf. Transportation standards are different.
The removal of the wire reel from the machine is recommended before undertaking any lifting operation.

SETTING UP THE MACHINE

Rules to follow:
• Put the machine on the floor (maximum incline of 15°.)
• Ensure the work area has sufficient ventillation for welding, and that there is easy access to the control panel.
• The machine must be placed in a sheltered area away from rain or direct sunlight.
• The machine must not be used in an area with metal dusts.
DEVICE PRESENTATION (FIG-1)
1 - Screen + buttons
2 - + polarity plug
3 - - polarity plug
4 - Gas connection for torch
5 - Trigger connection
CONTROL BOARD (IHM) (FIG-2)
The control board is made of a colour TFT screen and two potentiometers. How it works in 3 states:
State 1 or Standby mode: with the potentiometer 1 you will be able to set the welding current, and with the potentiometer
2 the parameters related to the welding current.
State 2 or Welding mode: by pushing the potentiometer 1 you will have access to the top menu. Then by turning the
button you will select the welding mode. You will exit this menu by waiting 8s or by pushing the potentiometer 2 ->
back to State 1.
State 3 or Welding parameters mode: by pushing the potentiometer 2 you will have access to the welding parameters
and you will see the selection by turning the button. You will exit this menu by waiting 8s or by pushing the potentiometer
1 -> back to State 1.
TIG 220 AC/DC
6 - Remote control connection
(remote control)
7 - ON / OFF switch
8 - Power supply cable
9 - Gas inlet
