Schreder TFLEX MODULE Installationsanleitung Seite 4

D
SUSPENDED SWIVELING FIXATION, PULL OUT
431,5
A3
1228,5 mm
A1
48.36 in
839,5 mm
A2
33.05 in
450,5 mm
A3
17.73 in
1
01-55-961 | DOC-0018755 rev J | 03-2022
1169,5
A1
780,5
A2
440 mm
B
17.32 in
1
2
22.5
www.schreder.com
B
169,5 mm
kg/lb
C
6.67 in
±1 kg
402,5
R4.5
24
440
IK09
Ansi3G
C
8 kg
1OB
17.6 lb
15 kg
2OB
33.06 lb
23 kg
3OB
50.70lb
1
2
15
22.5
4/17
