Schreder TFLEX MODULE Installationsanleitung Seite 15

H
1195 mm
A1
47.04 in
806 mm
A2
31.73 in
417 mm
A3
16.41 in
1
01-55-961 | DOC-0018755 rev J | 03-2022
HOOK FIXATION
A2
A3
440 mm
B
17.32 in
Adjust hooks following cable tray size
W100 400 mm (25mm steps)
www.schreder.com
Ansi3G
A1
225,5 mm
C
8.88 in
C
B
8 kg
GB + 1OB
17.6 lb
15 kg
GB + 2OB
kg/lb
33.06 lb
±1 kg
23 kg
GB + 3OB
50.70 lb
111 mm
4.37 in
15/17
