Montage des Schlauchstop's
Montage du stop
Montagio del stop
Montaje del stop
Installation of limit stop
ø35mm /
1 3/8"
S36
Radius min.
= 50mm / 2"
Z.503.315
c
c =
480 mm / 18 15/16"
d =
360 mm / 14 3/16"
d
ø36mm /
1 7/16"
Verlängerungsmutter L= 40mm
Ecrou allongé L= 40mm
Dado prolungato L= 40mm
Tuerca de prolongación L= 40mm
Extension nut L= 40mm / 1 1/2"
