Outwell LEONIS LUX Bedienungsanleitung

LEONIS LUX
MODEL: 651239 ( CREAM WHITE )
MODEL: 651240 ( SHADOW GREEN )
1. BUTTON
7. LAMP BODY
2. LAMPSHADE
( EXTENDED )
4. ADJUSTABLE
HANGING POINT
5. CORD WITH
USB PLUG
3. LAMPSHADE ( COLLAPSED )
6. EDGE OF
LAMPSHADE
UK: INSTRUCTION MANUAL
Light modes:
• Press the button (1.) to switch on / off
the light.
• Press and hold the button to dim the
light. The light can be dimmed step-
less to any setting between maximum
and minimum light output.
Use of the lamp:
• Connect the USB plug (5.) to a reliable
power source.
• To extend lantern lampshade, grab
the edge of the lampshade (6.) and
push the body out from the inside, do
not pull on the cord.
• To collapse the lampshade, reverse
the above.
• Hang lamp from the hanging point,
adjust height as needed by gently
moving the cord through the adjuster.
• For indoor use only.
• Lamp can be cleaned
with a damp rag.
• Do not use corrosive
liquids to clean the lamp.
• Do not stare into the light source.
Light source: LED
This product contains a
light source of energy
efficiency class E.
The light source is not
replaceable. This would
introduce weak points in
the construction, that could reduce the
lifetime of the product.
Instruction for removal of light source
by market surveillance authorities:
1) Remove lamp lens by using a flat-
head screwdriver to open the four tabs.
2) Unscrew 2 pcs screws holding PCB
with LEDs in place.
3) Cut needed wires to remove the
required components for testing.
Instruction for disassembly of lamp
for disposal of components
when lamp has reached the
end of its usable life:
- See steps 1-2 above
3) Cut wires and remove screws
to allow removal of electronics on
circuit board. Dispose of electronics
according to local regulations.
4) Dispose of remaining components
according to local regulations.
Technical data:
5V, ,1.5A, 7.5W
Class 3 appliance
