Installation and Operating Instructions
EN
CHAPTER 3

TECHNICAL DATA

Flat Centrifugal Fan Boxes – SlimVent SV..
3.1

SlimVent SV.. type overview

A B C*
SVR 100 C 330 314 135 ø100 310
SVR 125 B 330 314 160 ø125 310
SVR 160 K 390 362 196 ø160 368
SVR 200 K 390 372 236 ø200 368 111
* Dimensions incl. brackets
1) with one operating level
3.2

Type plate

Example:
➌
➏
➒
⓬
Fan type plate key:
➊ Manufacturer's address
➋ Fan label:
CE = CE mark
➌ Version:
SVS = type designation
= size
200
➍ Item number
➎ Production code / year of manuf.
Ref. no., SNR (serial number) and PC (production code) number clearly identify the fan.

3.2.1 Motor type plate

Technical data about the motor can be found on the motor type plate!
Dim. in mm
Dim. in mm
D E F G
61 48 SVS 125 B 330 314 210 ø125 310
73 48 SVS 160 K 390 362 246 ø160 368
91 47,5 SVS 160 L 390 362 246 ø160 368
48 SVS 200 K 390 372 286 ø200 368 111
➊
➍ ➎
➐ ➑
➓ ⓫
⓭
➏ Nominal voltage / Frequency
➐ Current in rated operation / Current in reg. operation
➑ Total input power
➒ Nominal speed / Motor insulation class
➓ max. flow medium temp. at rated / regular operation
⓫ Cosine
⓬ Capacitor / protection class
⓭ Installation and operating instructions/ Print no.
4
SlimVent – Flat Centrifugal Fan Box
with two performance levels
Series
SVR 100 C
SVR 125 B
SVR 160 K
SVR 200 K 1)
Energy-efficient, backward-curved high
performance centrifugal impeller
SlimVent – Flat Centrifugal Fan Box
with two performance levels
Series
SVS 125 B
SVS 160 K
SVS 160 L
SVS 200 K 1)
Energy-efficient, backward-curved centri-
fugal impeller. Soundproofed with 50 mm
thick mineral wool lining
A B C* D E F
73
91
91
Fig. 1
➋
Ref. no. 2658
Ref. no. 2671
Ref. no. 2672
Ref. no. 2673
Ref. no. 0130
Ref. no. 0131
Ref. no. 2653
Ref. no. 0132
G H I
48 190 124
48 220 142
48 220 142
48 220 162
