Specifications
Height / Width / Depth:
Weight:
Power supply:
Cooling system:
Automatic Gain Control:
Metal Loss Correction (MLC):
Operational range:
Loop output:
Loop current:
Loop tension:
Loop resistance DC:
Frequency range:
Inputs:
MIC1/LINE1
MIC2
LINE2
LINE3
Outputs:
Loop connector
33 mm x 167 mm x 97 mm
442 g
100 - 265 V AC 50 / 60 Hz
Fanless
Speech-optimised, dynamic range: > 40 dB
0 - 4 dB / octave
0°C - 45°C, < 2000 m above sea level
2,5 A RMS
12 V RMS
0,2 - 3,0 Ω
80-6000 Hz (+/- 1,5 dB)
Mic and Line Level, 3-point Euroblock plug
5-20 mV / 2 kΩ / 48 V (MIC)
25 mV - 0.7 V / 10 kΩ (LINE)
5-20 mV / 2 kΩ / 5 V
Line Level, 3-point Euroblock plug
H: 25 mV - 100 mV / 10 kΩ (LINE)
L: 100 mV - 0.7 V / 10 kΩ (LINE)
Line Level, 3,5 mm stereo jack socket
25 mV - 0.7 V / 10 kΩ (LINE)
2-point Euroblock plug
