J
Fix the spring.
Clip the spring into the
body slot and thread it into
the screw.
Put φ 10 gaskets,insert
cotter pin to fix them.
H
Fix the auxiliary wheel.
• Place the auxiliary wheel, φ 10 gaskets, and M8 nuts on
the rear axle in turn, fix the M8 nuts with the M8 wrench.
• Fix M8 * 30mm screws with M8 wrench as shown in the
figure.
12
M
Fix the exhaust pipe.
Clip the exhaust pipe into the body orifice.
Fix it with M4 * 10mm round head screw.
DASHBARD DIAGRAM
Rotate the seat cushion latch, open the seat cushion, find the power cable,
connect the power supply, and then install the seat cushion again. Rotate
the seat cushion latch and secure it.
