HOW TO CHANGE THE BATTERY
1. Hold the handpiece in the palm of your left hand.
2. Use your right hand to turn the bottom of the handpiece approximately 10 degrees anti-clockwise (twist then pull, Figure 9).
3. Carefully remove the battery from the handpiece.
4. Insert a new battery and lock in position twisting it 10 degrees clockwise (push then twist, Figure 10).
5. Turn ON the Radii Xpert handpiece and place it into the charging dock until status ring shows solid green.
Note: The LED attachment does not have to be attached to the handpiece to charge the battery.
6. Dispose of used battery in accordance to local regulations. Do not dispose with unsorted household waste.
Battery Life Expectancy: Battery life is dependent on the amount of use and LED effi ciency. SDI Ltd guarantees the battery to have a minimum
of 300 total discharges. To extend the life of your Radii Xpert battery, keep it on the charging dock at the end of each day if possible.
TROUBLE SHOOTING
PROBLEM
Handpiece status ring fl ashes red.
Handpiece status ring shows solid red.
Handpiece status ring fl ashes blue once
and goes OFF.
No light appears on the charging dock
when handpiece is docked.
Unit works fi ne yesterday but will not turn
on this morning.
No audio beep heard when connecting
with the handpiece.
The light intensity is too low.
The LCD on the handpiece fl ashes.
Battery shows corrosion or emits a
scorched odour.
The dental material does not
cure completely.
I want to delete my favourite setting and
go back to the factory setting.
The handpiece has been on the charger
overnight. Status ring still showing red and
handpiece felt very hot.
The light emission does not start when the
button is pressed.
The LED attachment does not fi t
the handpiece.
6 6
POSSIBLE CAUSE
Handpiece over heated.
Battery low.
Battery empty.
No power.
Moisture from condensation.
Battery empty.
1. Dirty or scratched lens cap.
2. Barrier sleeve.
Unit is in the setting mode.
Do not use unit.
Wrong attachment?
Charging problem. Battery may be at the
end of its useful life.
Battery is fl at.
Wrong Radii LED attachment.
SOLUTION
Allow handpiece to cool down before reuse.
Handpiece can still be used for curing. Return to
charging dock as soon as possible.
Return to charging dock for charging.
1. Check all connections are clean and properly
connected.
2. Ensure power outlet is switched ON.
3. If the above does not work, move the whole
unit to a different powerpoint.
4. Call your local SDI Ltd representative for repair.
1. Check for sign of moisture inside the barrier
sleeve.
2. Remove barrier sleeve and allow unit to dry for
a few hours.
Return to charging dock for charging.
Check and clean lens cap. Replace if required.
Ensure barrier sleeve fi ts tightly over the emission
tip.
Press once to come out of the setting mode.
Call your local SDI Ltd representative.
Ensure the correct LED attachment is used. Check
material specifi cations for curing requirement
from the manufacturer.
Place the handpiece on the charging dock.
Press (top & bottom button)
simultaneously for 1-2 seconds, then status ring
illuminates solid yellow for 4 seconds and returns
to factory setting.
Replace battery.
Return to charging dock for charging.
LED attachments from previous model of
Radii are not compatible with the Radii Xpert.
