SLEEP MODE

The Radii Xpert will go into a sleep mode (LCD turns OFF) when it is:
1. Sitting on the charging dock or
2. Not in use for more than 3 minutes
The unit will automatically wake up when removed from the charging dock. Press
If the unit turns OFF / goes into sleep mode outside the charging dock, press
OPERATION
1. Handpiece
LED ATTACHMENT PROGRAM
Standard curing •
attachment
•
(440 nm - 480 nm)
•
Note: Observe Instructions for Use of the
STATUS - WHILE CHARGING
Charging (low battery)
Charging in progress
Charge completed
HOW TO CHANGE THE LED (Figure 5)
To change the LED attachment, carefully pull off the LED attachment from the handpiece and click in a new LED attachment.
HOW TO CHANGE THE LENS CAP (Figure 6)
1. Turn the lens cap anti-clockwise to remove.
2. Replace with a new lens cap by screwing it on clockwise.
HOW TO SET FAVOURITE CURING TIME (Figure 7)
1. Press and hold for 1-2 seconds. Numbers on LCD start fl ashing.
2. Press to scroll up through the options from last setting used.
3. Press and hold for 1-2 seconds to save. Numbers on LCD stop fl ashing. Status ring illuminates solid green for 2 seconds with one short
beep, to confi rm selection is saved.
4. A star appears on the bottom left of the LCD screen. Unit is ready to use.
HOW TO ADJUST THE AUDIO VOLUME (Figure 8)
1. Press to turn the unit on.
2. Remove the LED attachment from the Radii Xpert handpiece.
3. Press and hold for 1-2 seconds to activate change mode.
4. Speaker symbol lights up.
5. Bar graph displays volume settings
6. Press to scroll through options. Buzzer will sound to demonstrate the volume level (mute, low, medium, high).
7. Press and hold for 1-2 seconds to save. Status ring illuminates solid green for 2 seconds with one short beep, to confi rm
selection is saved.
8. A star appears on the bottom left of the LCD screen. Re-insert the LED attachment. Unit is ready to use.
The audio will remain on the selected setting until the unit returns to the factory setting. To go back to the factory setting, place the
handpiece on the charging dock. Press
yellow for 4 seconds and returns to factory setting.
Default curing time: 20 seconds
LCD counting down
20, 19, 18....3,2,1
User option curing time:
2, 10, 20 seconds
material applied when selecting
curing time.
STATUS RING INDICATOR
Solid red
Pulsing green
Solid green
(top & bottom button) simultaneously for 1-2 seconds, then status ring illuminates solid
to start curing.
once to wake unit up. Press
STATUS - WHILE OPERATION
Positioning light (target assist)
Curing in progress
LED attachment too warm
(allow to cool)
Charge level low
2. Charging dock lights display (while handpiece is charging)
STATUS - WHILE CHARGING CHARGING DOCK
Charging (low battery)
Charging in progress
Charge completed
to start curing.
STATUS RING INDICATOR
Solid yellow
Solid blue
1 red fl ash, then shuts off
Solid blue for 1 second and
2 short beeps
INDICATOR
Solid red
Pulsing green
Solid green
