Bosch C10 charger I Operating instructions
Device description
(2)
1 Charger
2 Mounting hook
3 Mains cable with mains connection
4 Charging cable
(red and black, 18AWG cable)
5 (+) Terminal clamp (red)
6 (–) Terminal clamp (black)
7 Standby
10
(1)
(6)
(5)
(3)
(7)
(4)
(8)
8 Mode selection button
9 Battery status: very low (<4.5
V)
10 Battery status: OK (charged)
11 Battery status: charging in
progress
EN
(11)
(10)
(9)
