LOADING THE RACKS
CUTLERY RACK
UPPER RACK
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted: high position to place bulky
crockery in the lower basket and low position to make the most of the tip-
-up supports by creating more space upwards and avoid collision with the
items loaded into lower rack.
The upper rack is equipped with a Upper Rack
height adjuster (see figure), without pressing the
levers, lift it up by simply holding the rack sides,
as soon as the rack is stable in its upper position.
To restore to the lower position, press the levers A
at the sides of the rack and move the basket do-
wnwards.
We strongly recommend that you do not ad-
just the height of the rack when it is loaded.
NEVER raise or lower the basket on one side
only.
The third rack was designed to ho-
use the cutlery. Arrange the cutlery as
shown in the figure.
A separate arrangement of the cutlery
makes collection easier after washing
and improves washing and drying per-
formance.
Knives and other utensils with sharp
edges must be positioned with the
blades facing downwards.
Load delicate and light dishes: glasses,
cups, saucers, low salad bowls.
The upper rack has tip-up supports
which can be used in a vertical position
when arranging tea/ dessert saucers or
in a lower position to load bowls and
food containers.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable flaps can be fold or
unfold to optimize the arrangement of
crockery inside the rack. Wine glasses
can be placed safely in the foldable
flaps by inserting the stem of each
glass into the corresponding slots.
Depending on the model:
– to unfold the flaps there is needed
to slide it up and rotate or release it
from the snaps and pull it down.
– to fold the flaps there is needed to
rotate it and slide flaps down or pull it up and attach flaps to the
snaps.
LOWER RACK
(loading example for the lower rack)
POWER CLEAN®
Power Clean® uses the special water jets in
the rear of cavity to wash more intensively the
high dirty items. The lower rack has a Space
Zone, a special pull-out support in the rear of
the rack that can be used to support frying
pans or baking pans in upright position, thus
taking up less space.
Placing the pots/casseroles faced to the Power Clean® component please
activate the POWER CLEAN® on the panel.
How to use Power Clean®:
1. Adjust the Power Clean® area G
folding down the rear plate hol-
ders to load pots.
2. Load pots and casseroles inclined
vertically in Power Clean® area.
Pots have to be inclined towards
the power water jets.
For pots, lids, plates, salad bowls, cutlery
etc. Large plates and lids should ideally
be placed at the sides to avoid interfe-
rences with the spray arm.
The lower rack has tip-up supports
which can be used in a vertical position
when arranging plates or in a horizontal
position (lower) to load pans and salad
bowls easily.
