Programming Software - Tell Adapter2 Schnell-Installationsanweisung

PROGRAMMING SOFTWARE:

The latest version of the programming software is available on the
manufacturer's website.
Permission levels:
The Adapter2 uses different user levels. The superadmin authorization level
used during the installation has full access to all settings in the device.
Default superadmin password: 1234
For more information on the permission levels, see the Installation and
Application Manual of the Adapter2.
Attention! It is highly recommended that you change the default passwords
after the first login. This can be done using the password icons in the
Connection type menu.
Connecting via USB
• Open the Adapter2 programming software.
• Power up the device and then connect it to the computer using a
USB-A to USB-B cable.
• Select the USB
• Enter the Device password (default password: 1234), and then click on the
Connect button.
• To configure the settings, first you must read the settings stored in the device
by clicking on the Read
menu group.
• Configure the settings as needed, and then write the changed settings into the
device by clicking on the Write
PIN-code, APN, and Cloud:
After the USB connection has been established successfully, select the General
settings menu. In the SIM section you can configure the SIM card's PIN code
and the APN specified by your provider, which is required to access the mobile
Internet.
Configure the Cloud usage in the Cloud server section.
Default cloud server IP address:
Default cloud server port:
:
option in the Connection type menu.
button in any submenu under the Device settings
button.
54.75.242.103
2020
4
