Temperature setting function
3 Temperature settings from CH1 to CH3.
The setting method is as follows:
To select the function you want to set, first press the function selection key at the bottom of the display
screen to select SOLDER or DESOLDER. After the selection is completed, the function indication key will point
to the function you selected. Please refer to the attached panel diagram.
After selecting the function, please select the temperature setting selection key, you can set three groups
of temperatures. If you want to set the first group, press 1 Then use the temperature adjustment button to
adjust to the temperature you want to set, and then press the SET button to save the temperature you set.
When setting the second group, press 2 and then adjust to the temperature you want and press SET to save
the second group of temperatures, and the third group will be SET in this way. When working with the set
temperature, the temperature you set will be displayed above the temperature set number you set. After
the three sets of temperature settings are completed, the settings can be changed at any time as needed.
The factory setting is 150°C for the first group, 300°C for the second group, and 450°C for the third group.
• SOLDER AND DESOLDER temperature display shares the same display screen, you can only see the
temperature display of one function at the top at the same time. If you want to see the temperature of
another function, please use the SOLDER and DESOLDER keys at the bottom of the screen to switch to
read the temperature data
Time extension function in order to prevent the tin from staying in the tip of the soldering iron after
releasing the button too quickly after using the soldering iron to remove the tin, this machine is equipped
with the function of removing the tin after a two-second delay after the switch is released.
Energy safe function if the machine is set 300C and not in use, it will enter a sleep model " - - - " after 20
minutes. Just pick up the soldering iron or press the soldering button to wake up.
• Fahrenheit and Celsius conversion: Unplug the soldering iron on SOLDER, then press the SOLDER key
and the number 3 key to switch.
4
EN
EN
Specification
Power Supply
Temperature Range
Dimension
MODEL RND 560-00264
230V/50Hz
100ºC - 500ºC
180x105x195mm
(W x H x D)
3.6kg (Controller)
Weight
4.5kg (Total Weight)
