KOFFERTRÄGER / SIDE CARRIER
festverschraubt /firmly bolted
YAMAHA Ténéré 700 / Rally
(2019-)
Art.Nr./Item-no.:
6534564 00 01
schwarz/black
Baubreite des Kofferträgers 56 cm
Width of the side carrier 56 cm
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
WICHTIG
IMPORTANT
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,wie man eine be-
stimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das ent-
sprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
YAMAHA Ténéré 700 World Raid
(2022-)
YAMAHA Ténéré 700 World Rally
(2023-)
Art.Nr./Item-no.:
6534579 00 01
schwarz/black
Kombinierbar mit Easy-/Alu-/Minirack
Carrier can be combined with Easy-/Alu-/Minirack
6534564 00 01 / 6534579 00 01
1
