6. Settings
1. Factory reset
Press and hold the reset button for at least 5 seconds, the indicator will stay in red for 10s when the
reset is complete. Please note that all con guration parameters will be reset after the device is reset or
removed from the network.
2. Pairing mode
a. Remove the device from a previous Zigbee networkIf it has already been added to one otherwise
pairing will fail.
b. Press reset button twice. The indicator start blinking blue and stays solid for 10s when Succeeds.
3. Remove: There are two methods to remove the device from the Zigbee Network.
Method 1. From your Zigbee hub interface, choose to delete or reset the device as instructed.
Method 2. Press the reset button for 3 times, the indicator starts blinking purple and will stay solid for
10s when removing the dimmer from the network is nished. Timeout 3mins.
4. TouchLink: Reset the dimmer if it is included in a Zigbee network.
a. Press the reset button for 4 times, the indicator will start blinking green and stays solid for 10s,
timeout 3mins.
b. Bring the remote controller within 10cm of the smart dimmer and set the remote controller into
TouchLink comminssioning.
Please note: If the device is not included in a Zigbee network, it can be connected to a maximum of 1
device via Touchlink.
5. Find and Bind: Please make sure the device and remote are already added to the same Zigbee
Network.
a. Press the reset button for 5 times, the indicator will start blinking yellow and stays soild for 10s.
b. Set the remote controller into nd and bind mode and enable it. Refer to corresponding remote.
