IT/XT TERMINALI OPERATORE UNIVERSALI
IT/XT UNIVERSAL OPERATOR TERMINALS
IT/XT TERMINAUX OPERATEURS UNIVERSELS
IT/XT UNIVERSELLE BEDIENTERMINALS
IT/XT TERMINALES DE OPERADOR UNIVERSALES
IT/XT 通用操作终端
Dimensioni - Forature / Dimensions - Holes / Dimensions - Trous / Abmessungen -
Bohrungen / Dimensiones y perforaciones / 外观尺寸-开孔尺寸
IT105 - XT105
Rev. 5
Date: 18/02/2015
405.1300.145.0
Werbung
Verwandte Anleitungen für ESA IT105
Inhaltszusammenfassung für ESA IT105
- Seite 1 IT/XT TERMINAUX OPERATEURS UNIVERSELS IT/XT UNIVERSELLE BEDIENTERMINALS IT/XT TERMINALES DE OPERADOR UNIVERSALES IT/XT 通用操作终端 Dimensioni - Forature / Dimensions - Holes / Dimensions - Trous / Abmessungen - Bohrungen / Dimensiones y perforaciones / 外观尺寸-开孔尺寸 IT105 - XT105 Rev. 5 Date: 18/02/2015 405.1300.145.0...
- Seite 2 Posteriore / Rear side / Face arrières / Rückseite / Posterior / 背部面板 IT105 - XT105 A Connettore di alimentazione. D USB-B Power supply connector. Porta seriale per il trasferimento del progetto. Connecteur d'alimentation. Serial port to transfer the project.
- Seite 3 Alimentazione / Power supply / Alimentation / Spannungsversorgung / Alimentación / 供电 Power supply 4 pins connector +L 24 VDC M 0 V Not connected PE Protective ground Attenzione: Queste due configurazioni danneggiano gravemente il IT/XT. +24V Warning: These two configuration will seriously damage components.
- Seite 4 USBVCC (OUT) USBVCC (IN) USBD- USBD- USBD+ USBD+ Signal GND Signal GND N.C. N.C. N.C. : Not connected. N.C. N.C. ESA elettronica S.p.A. Via Padre Masciadri, 4/A I – 22066 Mariano Comense (CO) Tel. ++39-031757400 Fax ++39-031751777 web: http://www.esa-automation.com e-mail: customer.care@esahmi.com...
