11 Pressure guages

Working air is not available until the compressor has raised the TANK (tank) pressure above the pressure set at the
TOOL (tool) pressure gauge. It may take a few moments for tank pressure to build.
– TANK (tank) pressure gauge: Shows reserve air pressure in the tank.
– TOOL (tool) pressure gauge: Shows air pressure available at the outlet side. This pressure is controlled by the
regulator and is always less than or equal to the tank pressure.

12 Troubleshooting

Important:
If any parts are damaged or need replacing, consult a specialist workshop or contact customer service.
Problem
Compressor does not
start.
The compressor starts
but there is no outlet
pressure.
When the compressor
starts, pressure is shown
on the pressure gauge,
but there is no pressure
at the end of the high-
pressure hose.

13 Cleaning

Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions. They damage the hous-
ing and can cause the product to malfunction.
– Do not immerse the product in water.
1. Disconnect the battery pack(s).
2. Clean the product with a dry, fibre-free cloth.
3. Use a vacuum cleaner with soft brush to remove any blockages from the air intake filter.
30
Possible cause
No power supply.
Ambient temperature too low.
Motor has overheated.
The non-return valve has leaks.
The seals are damaged.
Drain valve for condensation has a
leak or is not fully closed.
The hose connections have a leak.
A quick-connect has a leak.
Insufficient pressure is set on the
pressure regulator.
Suggested solution
Check the rechargeable batteries.
Never operate when ambient temperature is
<5 ºC.
Switch the power OFF. Remove any conditions
causing the overheating and/or allow the motor
to cool down.
Check the non-return valve. Replace if neces-
sary.
Check the seals for damage. Replace if neces-
sary.
Check the drainage valve. Replace if neces-
sary.
Check the compressed air hose and connected
accessories. Replace if necessary.
Check the quick-connect. Replace if necessary.
Use the pressure regulator to increase the set
pressure.
