♦ Fit the collet chuck
ATTENTION! Do not tighten the union nut
with the open-ended spanner
bit is fitted. Otherwise, the collet chuck may be
damaged.
♦ Release the spindle locking button

Fitting the parallel fence

♦ Secure the parallel fence
fence mount using the locking screw
Adjust the parallel fence
screw on the underside of the parallel fence
NOTE
♦ You can also attach the parallel fence
the back side of the edge routing module
But first you must remove the locking screw
and mount it on the edge routing module
Charging the battery pack (see fig. A)
CAUTION!
► Always unplug the appliance before you
remove the battery pack from or connect
the battery pack to the charger.
NOTE
► The recommended ambient temperature
range for using tools and batteries is between
-5°C and 50°C.
► Never charge the battery pack at an ambient
temperature of below 10°C or above 40°C.
If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level
is between 50% and 80%. The storage cli-
mate should be cool and dry, and the ambi-
ent temperature should be between 0°C and
50°C.
♦ Connect the battery pack
charger (see fig. A).
♦ Plug the mains plug into the mains power socket.
The green charge indicator LED
briefly, then the red indicator LED
PMFAP 20-Li A1
(6 mm).
unless a router
.
to the parallel
.
by loosening the
on
to the high-speed
lights up
lights up.
♦ The green charge indicator LED
that the charging process is complete and the
battery pack
ATTENTION!
♦ If the red charge indicator LED
this means that the battery pack
heated and cannot be charged.
♦ If the red and green charge indicator LEDs
both flash, this means that the battery
pack is defective.
.
♦ Push the battery pack
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the power plug from the mains pow-
.
er socket.
.
Inserting/removing the battery
pack
Inserting the battery pack
♦ Click the battery pack
multifunction router
Removing the battery pack
♦ Press the release button
battery pack

Checking the battery charge level

♦ To check the battery status, press the battery
charge level button
The status/remaining charge will be shown on
the battery display LED
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
indicates
is ready for use.
flashes,
has over-
into the appliance.
into the cordless
.
and remove the
.
.
as follows:
