Please reserve at least 5 mm for pro-
file jointing to enable enough space
for contraction and expansion.
Install the screw into po-
Screw head above to
sition and ensure the
the base of aluminum
screw head is flush or
profile.
lower the base of
aluminum profile.
PROFILE TRANSITIONS:
angular misalignment
parallel vertical
misalignment
BENDING IN THE PROCESS OF INSTALLATION:
Installing angle should be less than 15 degree when pressing the
light to the aluminum profile by hand.
The circuit board could be damaged if installing angle larger than 15
degree.
Gradient installing of
screw.
DISTANCE FOR INSTALATION OF INFEEDER AND
END CAP:
10-20 mm
Keep 10~20 mm distance from the infeeder.
10-20 mm
parallel horizontal
Keep 10~20 mm distance from the infeeder and the end cap.
misalignment
The space between the infeeder and the mounting profile less than
10 mm is forbidden.
The space between the infeeder/the end cap and the mounting profile
less than 10 mm is forbidden.
Install the light in one direction, no matter what kind of connector used.
Don't let it choke in middle.
10-20 mm
10-20 mm
Carl-Zeiss-Str. 13
28857 Syke
