Manual
Platin SVQ Single
IP68
TECHNICAL DATA:
24 V power supply with
Power supply
constant voltage output
Power/m
12 W
Current strength/m
0.5 A
Quantity LED/m
108
LED spacing
9.26 mm
Dimension of segments
18.52 mm, 2 LEDs
Maximum length per connection
Length
15 metres
Dimensions
18.52* x 16 x 17 mm
Bending diameter
min. 300 mm
Temperature range
-45° C to +70° C
Processing temperature
+10° C to +70° C
* Section length | module
NOTICE:
This product contains a light source of energy efficiency class E.
INSTALLATION NOTE:
The outer jacket of the product has an expansion factor of 0.05%, e.g.
operating length of 10.000 mm ≙ an expansion factor of ± 5 mm.
IMPORTANT INSTALLATION INSTRUCTIONS:
1. Be sure to have a professional electrician complete installation.
There is no warranty coverage for any lights installed without ob-
serving European safety directives.
2. Switch off voltage prior to installation. Ensure that voltage cannot
be accidentally switched on again.
3. VARDAFLEX LED strips is suitability for direct mounting on normal
flammable surfaces, e. g. on wood and wood-based materials with
more than 2 mm thickness.
4. Before turning the power on, check all connections for correctness
and short-circuit.
5. Never operate the LED strips when rolled up.
6. Cut the strips exactly at the specified severing lines.
7. Please make sure that an appropriate flex cross-section for the
connection between LED strip and controller is used.
8. Do not exceed the operating temperature of +70° C.
9. Please do not carry out any repairs yourself. Failure to comply may
lead to voiding of the manufacturer's guarantee.
HANDLING:
Light emitting surface
Light emitting surface
Light emitting surface
MOUNTING LED-STRIP:
CAUTION:
Do not install VARDAflex LED strips in a suspended way!
Light emitting surface
Light emitting surface
