Installation Guide

4 . Technical Specifications

EN
Specifications
Operating
Operating Voltage
Output
Setting temperature range
Operating temperature
range
Battery life
Switch rating
Switch type
Terminals
IP rating
Load compensation control Yes
On/off control
ErP class
Construction
Pollution Degree Rating
Rated impulse voltage
Ball pressure test
Dimensions
Software classification
Running and setting
accuracy (for thermostats
with build in timer)
6 Danfoss Climate Solutions | AN30483451554601-010102 | 06/2023
RET2001B & TP5001B
RET2001B / TP5001B
Product is designed
for continuous use
2 .5–3 VDC
(2 x AA alkaline batteries)
Volt free
5 °C to 35 °C
0 °C to 40 °C
2 Years
3A (1) at 250Vac
1x SPDT Type 1B
1 to 2 .5 mm2 wires
IP30 (installed)
Yes
Class IV, efficiency gain 2 %
EN60730-2-9
Degree 2
4 kV
75 °C
H86 x W86 x D28
A
Setting resolution
1 minute . Accuracy
+/- 1 minute per month .
