32 Gasket
33 Sensor wire

Assembly instruction

Step 1 Faster the front stabilizer (3) on the main
frame (1) with screws, washers and nuts (26,32,31);
then Faster the rear stabilizer (2).on the frame with
screws washers and nuts (26,32,31).
Step 2 Fasten the Pedal L to the crank L, and fasten the Pedal
R to the Crank R (14, 15).
NOTE that the Right Pedal should be threaded on clockwise
and the left pedal anti-clockwise.
Step 3 Fasten the Seat post (9) into main frame (1). Then insert
Adjusting seat post frame with seat (8) in the Seat post (9) and
lock with L Knob (21) .
₵10.5*₵22*1.5T 4
