Multi-GPU
LAN
Wireless LAN &
Bluetooth®
Audio
Storage
RAID
Continued from previous page
∙ Supports 2-Way NVIDIA® SLI® Technology
∙ Supports 3-Way AMD® CrossFire™ Technology
1x Realtek® RTL8125 2.5 Gbps LAN controller
Intel® Wi-Fi 6 AX200
▪ Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-
5GHz (160MHz) up to 2.4Gbps
▪ Supports Bluetooth® 5
▪ The Wireless module is pre-install in the M2_4 (Key-E)
slot
Realtek® ALC1220 Codec
∙ 7.1-Channel High Definition Audio
∙ Supports Optical S/PDIF output
AMD® X570 Chipset
∙ 4x SATA 6Gb/s ports
∙ 2x M.2 slots (M2_2/ M2_3, Key M)*
▪ Support PCIe 4.0/ 3.0 x4 and SATA 6Gb/s
▪ Support 2242/ 2260 /2280 storage devices
AMD® Processor
∙ 1x M.2 slot (M2_1, Key M)*
▪ Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
▪ Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™
with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™
with Radeon™ Graphics)
▪ Supports 2242/ 2260 /2280/ 22110 storage devices
*The speeds may vary for different devices
∙ Support RAID 0, RAID 1 and RAID 10
Continued on next page
