ArmorKinetix 2090 Hybrid Cables and Terminators Product Information
Specifications
These cable pinouts apply to the ArmorKinetix 2090 hybrid cables. For complete information on these hybrid cables see ArmorKinetix 2090 Cables and Connectors Installation Instructions, publication 2090-IN053.
ArmorKinetix PIM to DSx Hybrid Cable Pinout - 2090-CDHIFS-12AFxxxx
DC Bus
Connector
Connector
DC Bus
Connector
3
ArmorKinetix PIM Flying Lead End
2
RJ45
1
Connector
ArmorKinetix DSx to DSx Hybrid Cable and ArmorKinetix DSx to DSx Zero Stack Jumper Cable Pinouts - 2090-CDHP1S-12AFxxxx and 2090-CDHP1S-12AFJ
Plug End
ATTENTION: To avoid electrical shock, make sure shielded hybrid cables are grounded at a minimum of one point. To prevent the buildup of electrical energy, factory-supplied power cables use one of
these grounding techniques:
• The overall shield is bonded to the connector housing.
• A section of the overall shield is exposed for connection to ground.
• The overall shield is connected to a ground wire.
ATTENTION: Do not tightly gather or coil the excess length of a power cable. Heat is generated within a cable whenever power is applied. Always position a power cable so it can freely dissipate heat.
Do not coil a power cable except for temporary use when building or testing a machine. If you temporarily coil a power cable, you must also derate the cable to meet local code or follow an authoritative
directive, such as Engineering Section 310.15(C) of the NEC Handbook.
Connector Terminator Dimensions - 2090-CDHT, 2090-CDFT, 2090-CDPT
Dimensions in millimeters (inches). Dimensions are not intended to be used for manufacturing purposes.
39.0 (1.53)
ArmorKinetix DSx Hybrid Connector
Output Terminator - 2090-CDHT
2
BROWN DC+
1
GREEN GND
2
BLACK DC-
3
WHITE
1
ORANGE
2
WHITE
3
GREEN
RJ45
6
WHITE
7
BROWN
8
WHITE
5
BLUE
4
CONNECTOR
CHASSIS
BROWN DC+
2
GREEN GND
PE
BLACK DC-
1
WHITE
A
ORANGE
B
WHITE
C
GREEN
D
WHITE
E
BROWN
F
WHITE
G
BLUE
H
CONNECTOR
CHASSIS
19.0 (1.75)
11.0 (0.43)
ArmorKinetix DSD Feedback
Connector Terminator - 2090-CDFT
Rockwell Automation Publication 2090-PC013A-EN-P - June 2023
12 AWG
BROWN DC+
12 AWG
GREEN GND
12 AWG
BLACK DC-
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
12 AWG
BROWN DC+
12 AWG
GREEN GND
12 AWG
BLACK DC-
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
24 AWG
CONNECTOR
CHASSIS
ArmorKinetix DSD Power Connector
Terminator - 2090-CDPT
SOCKET END
Socket End
2
PE
1
A
B
C
D
E
F
G
H
CONNECTOR
CHASSIS
Socket End
2
PE
1
A
B
C
D
E
F
G
H
38.0 (1.50)
30.0 (1.18)
