Functional Description

Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.
While reading the operating instructions, unfold
the graphics page for the garden product and
leave it open.
Intended Use
The garden product is intended for domestic
lawn mowing.
Delivery Scope
Carefully remove the garden product from its
packaging and check if the following parts are
complete:
– Lawnmower with handle assembly
– 2 Handle bottoms
– 2 Bolts
– 2 Wing nuts
– 2 Screws
– Grassbox top
– Grassbox bottom
– 1 Cable clip
– Operating instructions
When parts are missing or damaged, please con-
tact your dealer.
When fully assembled the machine weighs ap-
proximately 6.6 kg. If necessary, obtain assist-
ance to remove from packaging.
Take care when removing from packaging or car-
rying the machine to the lawn, as the blades are
sharp.
Product Features
The numbering of the garden product features
refers to the illustration of the garden product
on the graphics page.
1 Switch lever
2 Safety button
3 Handle top
4 Wing nut
F 016 L70 585 | (10.11.09)
5 Deflector guard
6 Handle bottom
7 Ventilation slots
8 Grass comb
9 Wheel
10 Grassbox
11 Cable restraint*/ **
12 Extension cable*
13 Power plug **
14 Blade
15 Blade washer
16 Blade bolt
17 Hole to lock the drive
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
** country specific
Technical Data
Lawnmower
Article number
Rated power input
Blade width
Height of cut
Grassbox, capacity
Weight according to
EPTA-Procedure
01/2003
Protection class
Serial number
The values given are valid for nominal voltages [U] of
230/240 V. For lower voltage and models for specific
countries, these values can vary.
Please observe the article number on the type plate of
your garden product. The trade names of the individual
garden products may vary.
Rotak 32
3 600 H85 B..
W 1200
cm 32
mm 20 – 60
l 31
kg 6.6
/II
See serial number
(type plate) on the
machine
