Quick installation guide IB-1817MCT-C31
Place the delivered thermal
pad directly onto the M.2 SSD.
Place the supplied heat sink on
the thermal pad and carefully
press it down.
Hint: Make sure that the heat
sink is inserted in the correct
direction.
Push the inner frame including
SSD and heat sink into the
housing. Make sure that the
inner frame is locked in place.
Hint: Make sure that the inner
frame points in the right direc-
tion. Both arrows must point to
the same side and be aligned
with each other.
